      Product description

      Need a Micro Pen Actuator with Feedback that delivers the premium results you're looking for? The Firgelli Micro Pen has been specifically designed to provide the performance you need, no matter what the nature of your business may be.

      Durable, High-grade Components

      Each Micro Actuator comprises high-grade components that have been built to a demanding specification and put together by time-served engineers. The result is a premium product that has been designed to deliver highly accurate results, even in challenging conditions.

      Created to provide robust, consistent performance, Micro Linear Actuators offer a dependable solution to your design and production requirements, no matter what your operation might be.

      Exceptional Performance

      If performance matters to you, then look no further than this actuator. Equipped with Hall sensor feedback, that results in an exceptional level of positional control, this Actuator also offers overload protection, which minimizes the risk of unexpected failure when it matters most.

      Modest Dimensions for Optimum Versatility

      One of the main reasons why a growing number of companies are choosing this Micro Pen Actuator for their operations is its relatively small dimensions - measuring just 16mm in diameter, it's still capable of offering forces up to 50N (11lbs) at the same time as providing stroke lengths up to 100mm (10cm or approximately 3.93701 inches.

      The Micro Pen Actuator With Feedback is Suitable for a Wide Range of Applications

      Whether you have a robotics operation and need a suitable Actuator that will deliver the results you're looking for or are involved in some form of consumer electronics, a Micro Pen Actuator with Feedback could be exactly what you're looking for. It's also a good option if your product has hidden flaps or panels that require specialist work.

      This Actuator is a versatile piece of equipment that's useful for environments where a high level of accuracy and detail is essential to good results.

      To synchronous 2 or more actuators together to run at exactly the same speed, we recommend our Control board FCB-1 for the ultimate Actuator control.  This gives you complete actuator control including adjusting limits, speed, and even a series of timer functions to be able to time when an Actuator opens and closes.


      Specifications
      FA-BS16-4-12-(Stroke) FA-BS16-11-(Stroke) FA-BS16-22-(Stroke)
      Push/Pull Force 20N (4.5-lbs) 50N (11-lbs) 100N (22-lbs)
      Static Force 30N (6.75-lbs) 75N (16.5-lbs) 140N (33-lbs)
      Speed at no load 15mm/sec  (0.6”/sec) 5.8mm/sec  (0.22”/sec) 3mm/sec  (0.11”/sec)
      Voltage 12V 12V 12V
      Max Current at full load 0.3A 0.3A 0.3A
      Duty Cycle 10%
      Operating Temp. Range 23°F to 149°F (-5°C to 65°C)
      Protection Class IP66
      No Load Noise Level 50-65 dB
      Diameter (16mm)  0.62"
      Mounting Ends Plastic O Type
      Screw Type ACME
      Outer Housing Material Aluminum T6063
      Expansion Rod Material Stainless Steel 304
      Limit Switch  Built-In non-adjustable
      Feedback Hall Effect Sensor (x2; 90 degrees phase)
      Repeatability 0.1mm positional repeatability
      Hall sensor pulses / revolution

      360PPR

      Hall Sensor Pulses / in.

      4 lbs - 508
      11 lbs - 920
      22 lbs - 1143

      Hall Sensor Pulses / mm

      4 lbs - 20
      11 lbs - 36
      22 lbs - 45

      Feedback Voltage 5V
      Synchronous Capability Yes, with a Microcontroller
      Cable Length 0.5 feet



      Stroke Length

      Retracted Length

      (Hole to Hole)

      Extended Length

      (Hole to Hole)

      Weight Gram (Ounce) STEP File
      20mm (0.78") 140mm (5.5")
      160mm (6.3") 49 (1.7)
      FA-PL100-12-20
      40mm (1.57") 160mm (6.3") 200mm (7.87")
      59 (2.0) FA-PL100-12-40
      60mm (2.36") 180mm (7.08") 240mm (9.44") 63 (2.22) FA-PL100-12-60
      80mm (3.14") 200mm (7.87") 280mm (11") 75 (2.64) FA-PL100-12-80
      100mm (4") 220mm (8.66")
      320mm (12.59") 81 (2.85) FA-PL100-12-100


      Dimensions

      3D Step Files

      FA-PL100-12-20

      FA-PL100-12-40

      FA-PL100-12-60

      FA-PL100-12-80

      FA-PL100-12-100

      Technical curves

      micro actuator force curves
