Lux To Footcandle Interactive Calculator

Lighting specs in North America use footcandles while the rest of the world uses lux — and converting between them by hand wastes time on every cross-border project. Use this Lux to Footcandle Calculator to convert illuminance values in both directions, and to calculate illuminance from point sources, required distances, luminous intensity, and average illuminance from total lumens. It matters in architectural lighting design, OSHA workplace compliance, and industrial machine vision — anywhere photometric specs cross international standards. This page includes the conversion formulas, a worked office lighting example, full theory, and an FAQ.

What is Lux to Footcandle Conversion?

Lux and footcandles both measure illuminance — how much light falls on a surface. One footcandle equals 10.7639 lux. To convert, you multiply or divide by that factor.

Simple Explanation

Think of illuminance like rainfall on a surface — it tells you how much light is hitting a given area, not how bright the surface looks. Lux measures that "rainfall" in metric (per square meter), while footcandles measure it in imperial (per square foot). The areas are different sizes, so the numbers are different — but they describe the exact same thing.

📐 Browse all 1000+ Interactive Calculators

Illuminance Comparison Diagram

How to Use This Calculator

1. Select a calculation mode from the dropdown — choose from direct lux/footcandle conversion, point source illuminance, required distance, luminous intensity, or average illuminance from total lumens.
2. Enter your known values into the input fields that appear — such as illuminance in lux or footcandles, luminous intensity in candela, distance in meters, total lumens, area, and utilization factor.
3. Check your inputs are positive non-zero numbers where required — the calculator will flag invalid entries before running.
4. Click Calculate to see your result.

Lux ⇄ Footcandle Calculator

Conversion Equations

Use the formula below to calculate lux-to-footcandle and footcandle-to-lux conversions.

Use the formula below to calculate illuminance at a surface from a point source using the inverse square law.

Use the formula below to calculate average illuminance from total luminous flux across a room or work surface.

Use the formula below to calculate illuminance when light strikes a surface at an angle rather than head-on.

Simple Example

Convert 500 lux to footcandles:

• Input: 500 lux
• Conversion factor: 10.7639
• Result: 500 ÷ 10.7639 = 46.45 fc

That's the ANSI/IES recommended level for general office work — 500 lux and 46.45 fc are the same illuminance, just expressed in different unit systems.

Theory & Practical Applications

Fundamental Photometric Concepts

Illuminance measures the luminous flux incident per unit area, representing how much visible light falls on a surface regardless of the surface's reflective properties. The distinction between lux and footcandles is purely one of measurement units — both quantify the same physical phenomenon. One footcandle equals the illuminance produced by one lumen uniformly distributed over one square foot, while one lux equals one lumen per square meter. The conversion factor of 10.7639 arises directly from the area ratio: (1 ft / 0.3048 m)² = 10.764 ft²/m². This factor is exact within the precision limits of the international foot definition.

A critical distinction exists between illuminance (light falling on a surface) and luminance (light emitted or reflected from a surface). Illuminance is objective and measurable with a light meter regardless of viewing angle, while luminance depends on both illuminance and surface reflectance characteristics. A white surface under 500 lux appears far brighter than a black surface under the same illuminance because the white surface has high reflectance. This distinction matters in practical applications: OSHA regulations specify minimum illuminance levels for workspaces, not luminance, because illuminance directly determines visibility regardless of the object being viewed.

The Inverse Square Law and Its Practical Limitations

The inverse square relationship E = I/d² derives from geometry: as distance doubles, the same luminous flux spreads over four times the area, reducing illuminance to one-quarter. This law applies strictly only to point sources — theoretical sources with zero physical dimensions. Real-world sources exhibit point-source behavior only when their largest dimension is less than approximately one-fifth the measurement distance. A 300mm diameter LED panel cannot be treated as a point source at 1 meter distance (300mm > 1000mm/5), but becomes a valid point source approximation at 3 meters or beyond.

At close range, the inverse square law systematically overestimates illuminance because it assumes all light originates from a single point. Extended sources require integration across the source geometry. For a uniformly luminous disk of radius r at distance d, the exact illuminance on-axis is E = L × π × [1 - d/��(d² + r²)], where L is the disk's luminance. At d = r, this yields 46% lower illuminance than the point-source approximation would predict — a non-negligible error in close-proximity lighting design. Industrial machine vision systems frequently encounter this limitation when using ring lights or LED panels positioned within 2-3 source diameters of the inspection target.

International Standards and Application-Specific Requirements

Lighting standards vary dramatically by application and regulatory jurisdiction. ANSI/IES RP-1-12 recommends 500 lux (46 fc) for general office work, 750 lux (70 fc) for detailed tasks like drafting, and 1000-2000 lux (93-186 fc) for precision assembly or inspection. European standard EN 12464-1 specifies similar values but adds uniformity requirements — the minimum illuminance cannot fall below 0.7 times the average across the task area. This uniformity criterion prevents excessive shadows and glare, which degrade visual performance even when average illuminance meets specifications.

Museum and gallery lighting operates under severely constrained illuminance limits to prevent photodegradation. Light-sensitive artifacts (textiles, watercolors, manuscripts) are limited to 50 lux (5 fc) maximum with strict annual exposure limits measured in lux-hours. Oil paintings can tolerate 150-200 lux (14-19 fc). These values represent compromises between visibility and preservation — lower illuminance extends artifact lifespan but reduces visitor experience quality. Modern museums increasingly use tunable LED systems that deliver higher illuminance when visitors are present and drop to minimal maintenance levels otherwise, reducing cumulative exposure while maintaining viewing quality.

Industrial Photometry and Measurement Considerations

Photometric measurements require cosine-corrected detectors that respond proportionally to the cosine of the incident angle. Uncorrected photodiodes or naked photocells exhibit angular response errors exceeding 20% at 60° incidence, leading to systematic measurement bias in multi-source environments where light arrives from various angles. Quality light meters incorporate diffuser domes with precisely engineered transmission characteristics to achieve f₂ < 3% deviation from ideal cosine response across the full hemisphere. These diffusers also provide spectral averaging weighted by the photopic luminosity function V(λ), ensuring the meter responds to light as the human eye does rather than measuring raw radiometric power.

Color temperature significantly affects perceived brightness even at constant illuminance. A 500 lux space illuminated by 2700K warm white LEDs appears dimmer than the same space under 5000K daylight-balanced sources, despite identical photometric measurements. This phenomenon arises from the Purkinje effect and chromatic adaptation — our visual system's spectral sensitivity shifts with adaptation state. Commercial and industrial lighting increasingly specifies both illuminance and correlated color temperature (CCT) to ensure consistent visual environments. Retail applications often use 3000-3500K to enhance warm colors in merchandise, while manufacturing inspection uses 5000-6500K for accurate color discrimination.

Worked Example: Commercial Office Lighting Design

Consider designing the lighting for a rectangular open-plan office measuring 18.3 meters × 12.2 meters (60 ft × 40 ft) with a ceiling height of 2.75 meters (9 ft). The target illuminance is 500 lux (46.5 fc) on the work plane at 0.75 meters (2.5 ft) above the floor. The design will use LED troffer fixtures, each containing 4800 lumens output at 4000K CCT with a symmetric direct distribution.

Step 1: Calculate total required lumens

Room area: A = 18.3 m × 12.2 m = 223.26 m²

For an office space with white ceiling (0.80 reflectance), light walls (0.50 reflectance), and medium furnishings, the Room Cavity Ratio is RCR = 5 × h_rc × (L + W) / (L × W), where h_rc is the cavity height from work plane to fixtures = 2.75 m - 0.75 m = 2.0 m.

RCR = 5 × 2.0 × (18.3 + 12.2) / (18.3 × 12.2) = 5 × 2.0 × 30.5 / 223.26 = 1.366

From IES coefficients of utilization tables for this RCR and reflectance combination with direct distribution troffers, CU ≈ 0.68. Applying a light loss factor of LLF = 0.80 (accounting for lamp depreciation, luminaire dirt accumulation, and room surface degradation over a 3-year maintenance cycle):

Total lumens required: Φ_total = (E_target × A) / (CU × LLF) = (500 lux × 223.26 m²) / (0.68 × 0.80) = 111,630 / 0.544 = 205,183 lumens

Step 2: Determine number of fixtures

Number of fixtures: N = 205,183 lumens / 4800 lumens per fixture = 42.75 ≈ 43 fixtures

Converting to footcandles to verify compliance with US standards: 500 lux / 10.7639 = 46.45 fc, which meets ANSI/IES RP-1-12 recommendations for general office work (30-50 fc).

Step 3: Fixture layout and spacing

For uniform illuminance, fixtures should be spaced at intervals not exceeding the spacing-to-mounting-height ratio (S/MH). For direct distribution troffers, maximum S/MH ≈ 1.3. Mounting height above work plane h_m = 2.0 m, so maximum spacing S_max = 1.3 × 2.0 m = 2.6 m.

Arranging 43 fixtures in a 6 × 8 grid (48 fixtures) with slightly reduced output per fixture provides better uniformity: longitudinal spacing = 18.3 m / 6 = 3.05 m, transverse spacing = 12.2 m / 8 = 1.525 m. The 3.05 m longitudinal spacing exceeds the 2.6 m maximum, so we use a 7 × 8 = 56 fixture layout: 18.3 m / 7 = 2.61 m (acceptable), 12.2 m / 8 = 1.525 m (well within limits).

With 56 fixtures at 4800 lumens each: actual total lumens = 56 × 4800 = 268,800 lumens. Actual average illuminance: E_avg = (268,800 × 0.68 × 0.80) / 223.26 = 653 lux (60.7 fc). This 31% over-lighting provides margin for depreciation and ensures no point falls below the 500 lux target. Installing dimmers allows operators to reduce output to 75% initially (490 lux), extending LED lifetime while maintaining specification compliance throughout the maintenance interval.

Step 4: Verification with point-source calculations

For a single fixture at mounting height h = 2.0 m directly above a point on the work plane, the inverse square law predicts: E_direct = I / h², where I is the luminous intensity downward. For a 4800-lumen symmetric direct distribution fixture, approximately 90% is directed downward (4320 lumens), distributed over approximately 2π steradians, giving average downward intensity I_avg ≈ 4320 / (2π) ≈ 688 candela.

E_direct = 688 cd / (2.0 m)² = 172 lux directly beneath the fixture

At a distance of 1.5 m horizontally from directly beneath, the slant distance d = √(2.0² + 1.5²) = 2.5 m, and the angle from vertical θ = arctan(1.5/2.0) = 36.9°. The illuminance with oblique incidence:

E_oblique = (I × cos 36.9°) / 2.5² = (688 × 0.800) / 6.25 = 88 lux

This single-fixture calculation shows significant variation. However, with 56 fixtures in the grid, each point receives contributions from multiple sources. The 4-5 nearest fixtures dominate, with their geometric contributions summing to provide the designed 653 lux average with uniformity ratio U₀ = E_min/E_avg ≈ 0.75, exceeding the EN 12464-1 requirement of 0.70 for office spaces.

This example demonstrates the distinction between theoretical point-source calculations and practical multi-fixture layouts. While individual source contributions vary by inverse square and cosine laws, carefully positioned arrays achieve uniform illumination through geometric overlap. The coefficient of utilization accounts for room-reflected contributions that simple inverse-square calculations neglect — reflected light can contribute 20-40% of total work-plane illuminance in high-reflectance environments.
