Rotating multi-link mechanisms — robotic arms, turntable-mounted actuators, CNC rotary tables — generate forces that don't show up in simple static load calculations. Use this Coriolis Force on Rotating Links Calculator to calculate both the Coriolis force and centripetal force acting on a moving mass using its weight, radial velocity, angular velocity, and radius. Getting these numbers right matters for robotic arm design, rotating machinery, and any precision positioning system where dynamic loads affect motor sizing or structural integrity. This page includes the governing formulas, a worked example, technical theory, and a full FAQ.
What is Coriolis Force on Rotating Links?
When a mass moves radially outward or inward along a rotating link, it experiences a Coriolis force — a sideways push perpendicular to its direction of travel. The faster the rotation and the faster the radial movement, the larger that force gets. Centripetal force acts at the same time, pulling the mass inward toward the rotation center.
Simple Explanation
Imagine sitting on a spinning merry-go-round and rolling a ball outward from the center — the ball curves sideways instead of going straight. That curve happens because of Coriolis force. On a rotating robotic arm, the same physics applies: any part that extends or retracts while the arm spins gets pushed sideways, and that sideways push creates real loads your motors and structure have to handle.
📐 Browse all 384 free engineering calculators
Rotating Link System Diagram
Coriolis Force Calculator
📹 Video Walkthrough — How to Use This Calculator
Coriolis Force interactive visualizer
Watch how Coriolis and centripetal forces change as a mass moves radially along a rotating link. Adjust the parameters to see real-time force calculations for robotic arms and rotating machinery design.
CORIOLIS FORCE
10.0 N
CENTRIPETAL FORCE
20.0 N
FIRGELLI Automations — Interactive Engineering Calculators
How to Use This Calculator
- Select your unit system — metric (kg, m, m/s) or imperial (lbm, ft, ft/s).
- Enter the mass of the moving object, its radial velocity (how fast it moves along the link), the angular velocity of the rotating system in rad/s, and the radius from the rotation axis.
- Double-check your angular velocity is in rad/s — if you have RPM, multiply by π/30 to convert.
- Click Calculate to see your result.
Simple Example
A 5 kg mass moves radially at 0.5 m/s along a link rotating at 2 rad/s, positioned 1 m from the rotation axis.
- Coriolis Force = 2 × 5 × 0.5 × 2 = 10 N
- Centripetal Force = 5 × 2² × 1 = 20 N
Mathematical Equations
Coriolis Force
Use the formula below to calculate Coriolis force.
Where:
- FCoriolis = Coriolis force magnitude (N or lbf)
- m = Mass of the moving object (kg or lbm)
- ω = Angular velocity of the rotating frame (rad/s)
- vr = Radial velocity relative to the rotating frame (m/s or ft/s)
Centripetal Force
Use the formula below to calculate centripetal force.
Where:
- Fcentripetal = Centripetal force magnitude (N or lbf)
- r = Distance from rotation axis (m or ft)
Vector Relationships
The Coriolis force vector is perpendicular to both the angular velocity vector and the radial velocity vector, following the right-hand rule. In a rotating coordinate system:
Technical Analysis and Applications
Understanding Coriolis and Centripetal Forces
In rotating mechanical systems, two primary fictitious forces arise when analyzing motion from the perspective of the rotating reference frame: the Coriolis force and the centripetal force. These forces are fundamental to understanding the dynamics of rotating machinery, robotic arms, and automated positioning systems.
The Coriolis force emerges when an object moves radially within a rotating reference frame. Named after French mathematician Gustave-Gaspard Coriolis, this force acts perpendicular to both the rotation axis and the velocity of the moving object. The magnitude is proportional to the cross product of angular velocity and radial velocity, scaled by twice the object's mass.
The centripetal force is the radially inward force required to maintain circular motion. Unlike the Coriolis force, which only appears when there is relative radial motion, the centripetal force exists whenever an object maintains a circular path in the rotating frame.
Engineering Applications
Robotic Arm Design
In multi-axis robotic arms, Coriolis forces become significant when the arm extends or retracts while rotating. These forces create coupling between joints, affecting trajectory accuracy and requiring sophisticated control algorithms. Engineers must account for these forces when sizing servo motors and designing control systems for FIRGELLI linear actuators used in robotic positioning systems.
Rotating Machinery
Centrifugal pumps, turbines, and compressors experience both Coriolis and centripetal forces on fluid particles and mechanical components. Understanding these forces is crucial for impeller design, bearing selection, and vibration analysis. In rotating equipment, the Coriolis force contributes to secondary flows and affects efficiency.
Precision Positioning Systems
CNC machines and automated manufacturing equipment with rotating tables must compensate for Coriolis effects during high-speed operations. The Coriolis force calculator helps engineers predict positioning errors and design feedforward compensation algorithms.
Worked Example: Robotic Arm Analysis
Consider a robotic arm with a 2 kg payload positioned 1.5 meters from the rotation center. The arm rotates at 0.5 rad/s while extending radially at 0.3 m/s.
Given Parameters:
- Mass (m) = 2 kg
- Radius (r) = 1.5 m
- Angular velocity (ω) = 0.5 rad/s
- Radial velocity (vr) = 0.3 m/s
Calculations:
Coriolis Force:
FCoriolis = 2 × m × vr × ω
FCoriolis = 2 × 2 kg × 0.3 m/s × 0.5 rad/s = 0.6 N
Centripetal Force:
Fcentripetal = m × ω² × r
Fcentripetal = 2 kg × (0.5 rad/s)² × 1.5 m = 0.75 N
The Coriolis force of 0.6 N acts perpendicular to the radial motion, creating a tangential load that the arm's servo system must overcome. The centripetal force of 0.75 N acts radially inward, contributing to the structural loading of the arm's support bearings.
Design Considerations
Control System Design
Modern servo control systems implement model-based feedforward compensation to counteract Coriolis forces. The control algorithm predicts the Coriolis force based on the current angular velocity and commanded radial velocity, then applies appropriate torque corrections to maintain trajectory accuracy.
Structural Analysis
Both forces contribute to the dynamic loading of rotating machinery. Structural engineers must consider these forces in fatigue analysis, bearing selection, and foundation design. The cyclic nature of these forces in multi-axis systems can lead to resonance problems if natural frequencies align with operational frequencies.
Motor Sizing
When selecting motors for rotating and extending mechanisms, engineers must account for the additional torque required to overcome Coriolis forces. This is particularly important for FIRGELLI linear actuators used in rotating applications, where the Coriolis force creates a time-varying load that affects motor performance and positioning accuracy.
Advanced Considerations
Multi-Link Systems
In complex multi-link rotating systems, Coriolis forces create coupling between different degrees of freedom. Each moving link experiences forces that depend on the motion of other links, leading to a complex dynamic system that requires sophisticated modeling and control strategies.
High-Speed Applications
At high rotational speeds, Coriolis forces can become the dominant dynamic effect. This is particularly relevant in applications like high-speed machining centers, where rapid tool movements combined with spindle rotation create significant Coriolis forces that affect surface finish and dimensional accuracy.
Vibration Analysis
Coriolis forces contribute to gyroscopic effects in rotating machinery. These effects can stabilize or destabilize the system depending on the configuration, making them important considerations in rotor dynamics and vibration analysis.
Understanding and properly calculating these forces is essential for engineers working with rotating mechanisms, automated systems, and precision machinery. The coriolis force calculator provides a quick and accurate way to quantify these effects during the design process, enabling better system performance and reliability.
Frequently Asked Questions
What is the difference between Coriolis and centripetal forces?
When are Coriolis forces significant in engineering applications?
How do I account for Coriolis forces in motor sizing?
Can Coriolis forces cause vibration problems?
What units should I use in the Coriolis force calculator?
How do Coriolis forces affect linear actuator selection?
