Hardenability Jominy Interactive Calculator

Choosing a steel grade for gears, shafts, or bearing races isn’t just about surface hardness—you need to know how far that hardness goes into the material and whether your quenching process delivers that depth. The Hardenability Jominy Interactive Calculator here lets you work out what hardness you’ll get at a given depth, plus critical diameters, cooling rates, and hardness ranges, based on your actual surface hardness, core hardness, carbon, grain size, and how aggressive your quench is. If you get this wrong—especially with driveline parts, gearboxes, or big load-bearing pieces—you can end up with soft spots under a hard shell, which means failures well before schedule. Below you’ll find the core equations, an example with numbers, practical background on martensite and alloying, and a FAQ based on what comes up in engineering work.

What is Jominy hardenability testing?

Jominy testing shows how deep you can harden a steel bar after heat treatment. You heat a standard bar, then cool one end fast with water—the way hardness changes along its length tells you how well that steel responds to different cooling rates. This is what predicts whether the steel will harden through or just at the surface in your real part.

Simple Explanation

Think of it like this: some steels will harden all the way through, others just on the skin. In the Jominy test, one end of a hot rod gets quenched, setting up a gradient of cooling from super-fast at the end to slow further back. Measuring hardness along the bar tells you how “deep” the hardness travels. The farther you can go from the quenched end and still measure good hardness, the higher the steel’s hardenability.

📐 Browse all 1000+ Interactive Calculators

Jominy Test Diagram

Hardenability Jominy Interactive Calculator

How to Use This Calculator

1. Pick which calculation you want: hardness at a point, distance for a desired hardness, ideal or actual critical diameter, cooling rate, or hardness band.
2. Type in the values for your case: surface and core hardness, distance from end, carbon, grain size, quench severity, or any tolerance if needed.
3. If you want an example, hit "Try Example"—it shows how real numbers link up between input and outputs.
4. Click Calculate to get your answer.

Hardenability Equations

Simple Example

Steel with surface hardness 60 HRC, core hardness 25 HRC, distance from quenched end = 10 mm:

• H_x = 25 + (60 − 25) × e^{−0.15 × 10}
• H_x = 25 + 35 × 0.2231 = 25 + 7.81 ≈ 32.8 HRC
• Cooling rate at 10 mm: CR = 1200 / (10 + 1.5)^1.7 ≈ 25.3 °C/s

Theory & Engineering Applications of Hardenability Testing

Hardenability tells you how deep you can get martensite, not just how hard something is at the surface. Hardness is about how tough the material is against indentation, but hardenability is about whether you can turn the steel structure to martensite all the way through for a given quench. You need to consider both—surface and core—when picking steel for parts with real thickness.

The Jominy End-Quench Test Methodology

The Jominy end-quench is the standard way to check steel hardenability. You use a 25.4 mm diameter, 102 mm long bar, heat it up into the austenite range (845–870°C for most medium-carbon steels), hold for a bit to dissolve carbides and get uniform structure, then move it to a fixture that runs a steady water jet against one end (typically 24°C water). The result is a severe quench at one end (over 300°C/s cooling), dropping to much slower cooling at the opposite end (<5°C/s).

After the quench, you temper the bar lightly (150–200°C) to relieve stress—only enough to keep hardness almost unchanged. Grind two flats along the specimen and measure hardness every 1.6 mm for the first 12.7 mm, then stretch out to every 3.2 mm. Plotting these gives you the Jominy curve, which tells you—very directly—how your steel responds to different cooling rates (the further from the end, the slower the cooling).

Microstructural Transformations and Cooling Rate Relationships

The variation in hardness you get on a Jominy bar matches the shift in steel structure as you change the cooling rate. Closest to the quenched end, you get an entirely martensitic structure—hardness maxes out, limited mainly by carbon content. For a 0.42% carbon steel, this is roughly 60–62 HRC. As you move along the bar, cooling rate drops off quickly (not in a straight line, but exponentially with distance). This is why the CR equation has a fractional exponent—it fits the real cooling behavior along a Jominy bar.

Where the cooling slows, you start to get a mix of martensite and bainite, then mostly bainite, pearlite, and even ferrite for the slowest parts. Each structure brings down the hardness. Martensite is the hardest (550–850 HV), lower bainite is next, then upper bainite, and finely divided pearlite. The final hardness you read out is the average from the mix at each location—how much of the microstructure is each phase and how fine it is.

Alloying Elements and Hardenability Multiplying Factors

Alloying elements buy you more hardenability by slowing down pearlite and bainite formation—basically, they give the steel more time to shift to martensite at the core. Manganese is cheap and effective (jumping hardenability at common levels), chromium is strong as well, and molybdenum, although costly, provides a big effect per percentage point. Nickel bumps up hardenability somewhat and is worth using where you also need toughness. Silicon adds a little but beware high silicon levels—they cause trouble with retained austenite and embrittlement if too high. Grain size is a wild card: big grains = higher hardenability, but also riskier for toughness and part distortion. The formula for grain size shows even one number difference makes a sizable odds change in diameter you can harden.

Critical Diameter Concepts and Practical Application

Ideal critical diameter D_I is just how thick a rod you could through-harden fully under the best quenching you could pull off (infinite quench). That’s not real life, so we scale it by H, the actual quench severity of your process. For agitated brine or water (very aggressive), H is about 1; for still oil, it’s 0.25–0.3; for air, it’s much less. With that, you get D_C, which lets you compare your part size to what your steel and quench setup can really give you. So you don’t have to run trial and error on full-size parts just to see if the core gets hard.

Sections that aren’t round get approximations for “ruling section.” For thick plates, it's about the same as the thickness; for rectangles, multiply thickness by about 0.9 to get the equivalent round diameter. These rules of thumb come from lots of shop-floor and stress analysis work—they do a decent job predicting what kind of hardening profile you’ll see in your actual component shape, without re-running Jominy tests for every new part.

Worked Example: Gear Material Selection for Wind Turbine Application

A wind turbine gear needs core and surface properties—minimum 58 HRC at the surface, 35 HRC at the core for a 180 mm diameter. Agitated oil quench is what’s available, and the steel is AISI 4340. Run the numbers for D_I using the carbon and alloying factors, and you’ll see the calculated D_C for oil quenching is several times bigger than the part (so you’ll get through-hardening at least at the center), but the surface needs more—carburizing or induction hardening is the right answer to hit those high surface numbers. This is practical—steel grades and processes get picked to match target hardness at relevant depths, not just “max up front” claims.

Temperature-Time-Transformation and Continuous Cooling Considerations

Jominy data ties to CCT diagrams via cooling rates, but the test itself doesn’t directly give you a CCT plot. The rate at each point in a Jominy bar is an average through the key temperature ranges where structure formation happens. Cooling isn’t constant and varies as the part cools down; rates used in Jominy plots are always approximate. For predicting part behavior, those values are fine for ballparks, but if you need super-precise numbers for big or odd-shaped parts, you’ll need finite element thermal models, not just Jominy data.

Martensite starts (Ms) and finishes (Mf) at certain temperatures. To get full martensite, you must cool fast enough below Mf before any pearlite or bainite forms. If cooling is slower, you get a mix. The Jominy bar is a practical, simple way to capture all these possible outcomes for a given steel batch, which is why it’s so handy for process planning and QC.

For advanced uses, you can plug Jominy data into simulation tools for heat treat distortion, where expansion from phase changes and cooling histories can predict if parts will warp after quenching. With good inputs from hardenability curves, some models now match final size to within tenths of a millimeter—good enough for high-value aerospace or drivetrain pieces that can’t tolerate much rework.

Practical Applications
