If you don’t know how much power your actuator will draw, expect headaches: undersized power supplies, dead batteries, or fuses blowing partway through a use cycle. This calculator gets right to the numbers—mechanical output power and current draw—using force, speed, and supply voltage. You need to know these actual power requirements whether you’re working on robotics, factory automation, or anything battery-powered. This page contains the basics, a step-by-step sample, detailed technical reference, and a practical FAQ.

What is actuator power consumption?

Actuator power consumption is simply the electrical power a linear actuator requires to move a load at a certain speed. The more force it pushes (or pulls), or the faster it moves, the more power it takes from the supply.

Simple Explanation

It’s no different than moving a box yourself: push harder or move it faster, and you need more energy. Linear actuators use this same physics—force times speed gives you the power needed. That’s the number that will determine your minimum power supply, battery size, or wire gauge.

📐 Browse all 1000+ Interactive Calculators

Actuator Power Consumption System Diagram

Actuator Power Consumption Calculator

How to Use This Calculator

1. Enter the actuator force — in Newtons or pounds — using the Force field and select your unit.
2. Enter the actuator speed — in mm/s or in/s — using the Speed field and select your unit.
3. Enter the supply voltage in volts (12V and 24V are the most common for linear actuators).
4. Click Calculate to see your result.

📹 Video Walkthrough — How to Use This Calculator

Mathematical Formulas

Simple Example

Force: 200 N
Speed: 50 mm/s (= 0.05 m/s)
Voltage: 12 V
Mechanical Power: P = 200 × 0.05 = 10 W
Current Draw: I = 10 ÷ 12 = 0.833 A

Complete Technical Guide to Actuator Power Consumption

Understanding Actuator Power Requirements

When you’re designing with FIRGELLI linear actuators, pinning down your real power consumption keeps projects on track. Power draw determines how long your battery lasts, sets your wire size and fuse rating, and tells you what power supply you’ll need. Underestimate it and you’ll see outages or overheated parts.

The power required comes straight from basic physics: force times speed. The calculator on this page sets a realistic baseline for your actuator’s mechanical power requirement, and you can size your electrical system from that.

Factors Affecting Real-World Power Consumption

There’s a difference between the calculated mechanical power and what the actuator actually draws electrically. Watch out for these main losses:

Motor Efficiency: Not all the electrical power goes to pushing the load. Small actuators with brushed DC motors usually waste more (60-75% efficiency typical). If you’re using brushless motors, you might squeeze out 80-90%. Basically, if you calculate 50 W of mechanical output, expect 60–85 W pulled from the wall.

Gearbox Losses: Most actuators use reduction gearing. Every gear set loses energy—often 85-95% efficiency per stage. Several gear stages, and the losses add up quickly.

Friction and Mechanical Losses: Bearings, seals, and guides always add force you don’t see on paper. As actuators age or if the temperature changes, friction can swing higher.

Control Electronics: Motor controllers, sensors, and any extra logic also need current. Usually these are small compared to the actuator itself, but in very low-power systems the control draw does matter.

Practical Applications and Examples

Here’s an actual use case: For an automated door, suppose you calculate 500 N to move at 25 mm/s (0.025 m/s) with a 24V supply:

Calculation:

• Force: 500N
• Speed: 25 mm/s = 0.025 m/s
• Voltage: 24V

Results:

• Mechanical Power: P = 500N × 0.025 m/s = 12.5 watts
• Theoretical Current: I = 12.5W ÷ 24V = 0.52 amperes

But if you factor in 70% efficiency, actual draw is closer to 17.9 watts and 0.75 amps. Those real figures are what you’ll need for your power supply, fuses, and wires—not just the theoretical outputs.

Power Consumption Optimization Strategies

If you need to keep overall draw down, these are the levers that matter:

Load Optimization: Use good bearings, keep rails straight, and grease the guides—every little bit of friction you remove saves wattage. Vertical loads can sometimes be counterweighted to lighten up the actuator’s job.

Speed Control: Power draw rises in direct proportion to speed. Go slower, and you reduce current. Applications that don’t need to be quick can use much less power just by lowering speed.

Duty Cycle Considerations: Most actuators don’t run constantly. Average power over an hour is usually much lower than peak, so you can engineer in smaller power supplies if you’re clever about energy storage and cycling.

Voltage Selection: Higher voltages cut current, especially over long wire runs, so you lose less to resistance. But don’t just boost voltage blindly—check what components you can actually source and wire safely at your site.

Battery Life Calculations for Mobile Applications

If you’re battery-powered, this calculator gives a rough starting point for life estimates. Battery capacity is rated in ampere-hours (Ah), which is just current × time.

So, if your actuator averages 0.75A and you use a 100 Ah battery, you’d expect up to 133 hours of run time—until you factor in efficiency, temperature, and battery age. In real builds, take off 20–40% for those effects.

Thermal Considerations

Lost power doesn’t just vanish—it turns into heat. The more inefficient, the hotter your actuator gets. You can estimate generated heat by subtracting mechanical output from total electrical input. For the door example: 17.9W in, 12.5W out, so about 5.4W becomes heat. That has to be carried away by the case and surrounding air, or the actuator may overheat on longer runs.

Power Supply Sizing Guidelines

Power supplies and fuses need to be sized for both steady-state and peak startup. Startup current for a typical brushed DC actuator can spike 3–5 times higher than the running draw. That means your 0.75A actuator could pull 2.3–3.8A just when starting—so don’t size your supply too close to the running current figure. A 24V/5A supply works well for this scenario.

Advanced Calculation Considerations

There are more things to watch for if you’re working with anything dynamic or complex:

Dynamic Loading: If your application starts and stops quickly, you’ll briefly need more power (F = ma). This is especially true for anything moving large masses or in a jolting motion.

Load Variations: Some mechanisms change required force through the stroke—thanks to angles, springs, or varying friction as parts move. Estimate force for the hardest point, or check profiles along the whole travel range.

Environmental Factors: Cold will increase startup force and friction; heat reduces what the motor can safely output. Plan for some derating if your application runs outside or in a tough shop environment.

Integration with Control Systems

Most modern actuators use control boards, sensors, or comms. Each extra bit of electronics adds modestly to current draw—especially with radios or frequent position checks. For a safe margin, set aside 10–20% extra supply capacity for controls.

Understanding actual actuator power needs means fewer surprises and less downtime—whether you’re building machinery, robots, or vehicles. Run the numbers up front, and use practical estimates for efficiency and losses: your designs will work better and last longer.

For more detailed engineering tools specific to actuators, check the available resources for calculators tackling mounting, reduction, and stroke specifics.
